Its resolution is 4,433% greater than
a typical fine art photograph.
It is one of the highest quality images
A lot of effort goes into a VAST photo, especially at sunset with rapidly changing light and in a harbor with moving boats and waves. There are several stages of work to any good photo: planning, shooting, post-processing, printing / display, and with panoramas you have to add stitching and blending of course. The planning phase is probably the most critical for a successful stitch later though. Location and time of day are obviously two important steps of planning, as is choosing your subject and field of view to know what focal length and aperture would best isolate your subject or place your subject in its environment. You may even have several subjects in a wide landscape. In this scene, the color of the sky, the reflection on the water, and the people getting off the boat on the pier were what I chose to be my focus. I let the railing and edge of shoreline be the natural border of the scene. I don’t always center my horizon line, but for a reflection it emphasizes the mirrored effect and it juxtaposed the dipping arch of the boats in the foreground lined up left to center below the horizon and the rising arch of the hill in the background from center to right above the horizon. The swooping S through the scene helps break up the centered horizon line.
Next was choosing my focal length, once I knew how much of the scene I was going to shoot. The horizontal angle of view was 160° wide, and it would take a non-existent 3.2mm lens to cover such an extreme angle, so it goes without saying that stitching multiple photos was obviously going to be the answer. But what focal length? 40mm would have covered the vertical field of view with a single row in portrait orientation and taken 6 images to reach 158° wide with a 25% overlap, but the resolution would only be 167 megapixels and I wanted much more detail, especially of the people on the distant dock. On the other hand, at 200mm it would have taken 31 columns of 6 rows for a total of 186 images and the stitched panorama would be 4.3 gigapixels, but I didn’t feel I had enough time with the people leaving the dock and setting sun to capture that many images. I also had moving boats and waves to contend with. In the end, I settled on 110mm and here’s the critical reason why: it captured the full mast and reflection of the tallest boat in the harbor in a single image, which would make masking and deghosting MUCH easier in post-production later when stitching and blending. It also meant I could capture the entire scene in 51 images (17 columns of 3 rows) before the light disappeared. I turned every 10° horizontally and 15° vertically for about a 39% horizontal overlap and 38% vertical overlap so I would have plenty of material for blending and deghosting moving boats and waves. It took about 6 minutes to capture all the images so the light was fairly consistent and the clouds didn’t move far. I started in the lower left hand corner and zigzagged so I would be shooting the darkest area first and the brightest area last for more even lighting, since the light was fading and the scene was getting darker. I would do the opposite for a sunrise panorama. The final, cropped image wound up being 65899 x 19926 or 1.3 gigapixels, so it was a good compromise and I still hit my goal of a gigapixel.
The hyperfocal distance of a 110mm lens at f/8 is 50m where everything from 25m to infinity should be acceptably sharp. This assumes a much smaller print size than zooming into 100% in a VAST photo though. I probably should have chosen at least f/11 or f/13 for more depth of field, but I was also down to 1/20 shutter speed and up to ISO 200 for an exposure and I didn’t want to raise my ISO to 2500. I couldn’t go with a longer shutter speed either without blurred boats from the waves. So I chose f/8, focused on a boat in the middle of the harbor (30m away), took a couple near and far test shots, and confirmed it was an acceptable compromise. Everything in photography is a compromise, as Joe DiMaggio is fond of saying!
Camera settings: 110mm, f/8, ISO 200, 1/20
Stitching data: 3 rows of 17 images.
Equipment used: Nikon D810, Nikon 70-200mm f/2.8 VR II, Promote Control, and Really Right Stuff TVC-34L tripod w/ leveling base & pano/gimbal head. RAW conversion in Lightroom, aligned with PTGui, and manually blended via masks in Photoshop. Planned with PhotoPills.
This 952-megapixel VAST photo is one of the highest definition photographs ever created. It has a resolution equivalent to 459 HDTVs.
|Aspect Ratio||3.46 : 1|
|File Size||5,440 MB|
|Width @ 300ppi (perfect)||15.94 feet|
|Height @ 300ppi||4.61 feet|
|Width @ 150ppi (near-perfect)||31.87 feet|
|Height @ 150ppi||9.22 feet|
|Date & Time||July 31, 2016: 8:05pm|
|Location||Seal Harbor, Maine|
|Number of Exposures||51|
VAST Prints are fine art photographic paper prints that arrive ready to be mounted and/or framed. They are created using the sharpest photographic printer in commercial use: a very rare specialty printer that formerly printed military surveillance imagery. Learn more
Every VAST Print has two certificates of authenticity hand-signed by the artist and the printmaker: one affixed to the print and one standalone. Additionally, each print is assigned a unique serial number via a permanent hologram seal and recorded in our registry. Its provenance is tracked and verified using state-of-the-art digital blockchain encryption technology.
VAST Displays are ready-to-hang works of art that contain a VAST Print sealed between flame-polished acrylic glass and an aluminum backing. A hidden brace on the back causes the display to gracefully "float" off the wall for a sleek, modern frameless look that complements nearly any decor style. Learn more
This VAST photo becomes a stunning conversation-starter wherever it's showcased. It's offered in 4 large-format sizes:
A license provides you with the full resolution digital image file and the right to use it for a specific project. Use the form below to begin the licensing process or click here to learn more
Contact one of our VAST experts to license this VAST photo:
